Chassis :
Carbonfibre monocoque structure
Front Suspension :
Upper and lower wishbones. Combined spring/damper
units mounted inboard with pushrod actuation. Choice
of twin or triple Stewart/Penske damper layout
Rear Suspension :
Upper and lower wishbones. Combined spring/damper
units mounted inboard with pushrod actuation. Choice
of twin or triple Stewart/Penske damper layout.
Front Brakes :
Twin AP Racing 4-piston calipers. Carbone Industrie
carbonfibre discs/carbonfibre pads
Rear Brakes :
AP Racing 6-piston calipers. Carbone Industrie
carbonfibre discs/carbonfibre pads
Wheels : BBS
forged magnesium; 12 x 13in frt, 13.4 x 13in r
Transmission :
Longitudinal semi-automatic six-speed gearbox.
High-pressure hydraulic system for power shift and
clutch operation. Choice of viscous or hydraulically
assisted differentials. AP Racing triple-plate
clutch.
Ford Zetec-R V10
Engine
Description :
72-degree
Displacement :
2,998 cc
No of Valves :
40 (lightweight barrel)
Length : 605mm
Width : 520mm
Height : 460mm
without airbox
Weight : 120kg
Fuel injection :
Ford Electronics
Ignition system :
Cosworth
